80 Scenario-Based CCNA Interview Questions (2027)
80 scenario-based CCNA interview questions with Cisco IOS commands: VLANs, trunks, STP, OSPF, NAT, DHCP, ACLs and Layer 2 security, by experience level.
Scenario-based CCNA interview questions describe a real fault or design request, such as a PC that gets a 169.254 address, a VLAN missing after a change, or OSPF neighbors stuck in EXSTART, and ask what you would check and which Cisco IOS commands you would run. Interviewers score your order of checks and your verification commands as much as the final fix.
This page has 80 scenario questions with answers, grouped by experience level and followed by multi-step troubleshooting tickets. The topics follow the Cisco CCNA 200-301 v1.1 exam blueprint, and the commands use standard Cisco IOS and IOS XE syntax. If you need definitions first (OSI layers, TCP vs UDP, what a VLAN is), start with our 150+ CCNA interview questions on networking basics and the OSI model guide, then come back for the scenarios.
Key takeaways
- Work bottom up in every answer: physical link, then Layer 2 (VLAN, trunk, STP), then Layer 3 (addressing, routing), then services (DHCP, DNS, NAT, ACLs).
- Name the verification command before the fix.
show ip interface brief,show interfaces trunk,show ip route,show ip ospf neighborandshow ip nat translationscome up in almost every interview. - Freshers are tested on addressing, subnetting, SSH setup, DHCP and basic switch ports. Engineers with 2 to 5 years are tested on trunks, STP, EtherChannel, OSPF, NAT, ACLs and Layer 2 security.
- Senior candidates are asked to design: campus topology, gateway redundancy, QoS, VRFs and automation with REST APIs, Ansible or Terraform.
- The CCNA exam code is 200-301. Cisco says the last day to test on v1.1 is 2 February 2027, and CCNA v2.0 goes live on 3 February 2027.
- Some interview favourites, such as EIGRP, BGP and HSRP configuration, sit outside the 200-301 v1.1 blueprint. They are marked below so you know which answers are exam material and which are job material.
How these scenarios map to the CCNA 200-301 blueprint
Cisco publishes the CCNA v1.1 exam topics as six domains. The exam is 120 minutes long. Use the weights to decide where to spend practice time.
| Domain (200-301 v1.1) | Weight | Where most related questions sit |
|---|---|---|
| 1.0 Network Fundamentals | 20% | 1 to 20 |
| 2.0 Network Access | 20% | 21 to 36 |
| 3.0 IP Connectivity | 25% | 37 to 49 |
| 4.0 IP Services | 10% | 50 to 59 |
| 5.0 Security Fundamentals | 15% | 60 to 68 |
| 6.0 Automation and Programmability | 10% | 69 to 75 (with design questions) |
| Mixed, multi-step tickets | All domains | 76 to 80 |
A simple answer pattern works for every scenario: state the most likely cause, say which command proves it, give the fix, then say how you would confirm the fix and stop it happening again.
Scenario-based CCNA questions for freshers
1. A user's PC cannot ping its default gateway. What do you check first?
Check the PC's own settings first, then the gateway interface. On the PC, confirm the IP address, mask and gateway (ipconfig /all on Windows, ip addr and ip route on Linux) and that the link light is on. On the router or Layer 3 switch, confirm the gateway interface is up/up and in the same subnet:
R1# show ip interface brief
R1# show running-config interface GigabitEthernet0/0
R1# show arp
If the router has no ARP entry for the PC, the problem is between them: cabling, the switch port, or the wrong access VLAN on the switch.
2. One user cannot reach the internet, but everyone else on the same switch can. How do you narrow it down?
Because other users work, the uplink, routing and NAT are fine, so focus on that one host and its switch port. Compare the user's IP settings with a working neighbour, ping the gateway, then ping a public IP, then a name. On the switch, check the port status, its VLAN and its error counters with show interfaces status and show interfaces GigabitEthernet1/0/5. A wrong access VLAN, a static IP typed with the wrong gateway, or a faulty patch cable are the usual causes.
3. A Windows PC shows a 169.254.x.x address. What does it mean and how do you fix it?
A 169.254.0.0/16 address is an automatic private (link-local) address. The PC asked for DHCP and got no reply. Check that the port is in the right VLAN, that the DHCP server or router pool has free addresses, and, if the server is on another subnet, that the gateway interface has a relay address configured:
R1# show ip dhcp pool
R1# show ip dhcp binding
R1# show ip dhcp conflict
R1# show running-config interface Vlan10 | include helper
4. A router interface shows "administratively down". What is wrong?
Someone shut the interface, or it was never enabled; router interfaces are shut down by default. Enable it and verify:
R1(config)# interface GigabitEthernet0/1
R1(config-if)# no shutdown
R1(config-if)# end
R1# show ip interface brief
5. An interface shows Status "up" and Protocol "down". What does that tell you?
Layer 1 sees a signal, but the data link layer is not working. On serial links the usual cause is an encapsulation mismatch (for example HDLC on one end and PPP on the other) or missing clocking. On Ethernet, look for errdisabled ports, a failing transceiver or a problem on the far end. Status down and protocol down usually means a cable, transceiver or far-end port that is off.
6. You need to manage a new Layer 2 switch from another subnet. What do you configure?
Give the switch a management IP on an SVI and a default gateway, because a Layer 2 switch does not route its own traffic:
SW1(config)# interface vlan 99
SW1(config-if)# ip address 10.99.0.11 255.255.255.0
SW1(config-if)# no shutdown
SW1(config-if)# exit
SW1(config)# ip default-gateway 10.99.0.1
The SVI comes up only when VLAN 99 exists and at least one port (access or trunk) in that VLAN is up. Using a dedicated management VLAN instead of VLAN 1 is the better practice.
7. Your manager asks you to replace Telnet with SSH on a router. What are the steps?
SSH needs a hostname, a domain name, RSA keys and a local or AAA user. Then restrict the VTY lines to SSH:
R1(config)# hostname R1
R1(config)# ip domain-name example.local
R1(config)# crypto key generate rsa modulus 2048
R1(config)# ip ssh version 2
R1(config)# username netadmin privilege 15 secret <strong-password>
R1(config)# line vty 0 4
R1(config-line)# transport input ssh
R1(config-line)# login local
Verify with show ip ssh and show ssh. Telnet sends passwords in clear text, which is why it should be disabled.
8. You made changes on a router, it reloaded after a power cut, and the changes are gone. Why?
The changes were only in the running configuration, which lives in RAM. The router boots from the startup configuration in NVRAM. Save after every verified change:
R1# copy running-config startup-config
write memory does the same thing. Many teams also keep off-box copies with copy running-config tftp: or a configuration backup tool.
9. Split 192.168.10.0/24 into four subnets of at least 50 hosts each. What do you use?
Use /26 (255.255.255.192). Each /26 has 64 addresses and 62 usable hosts:
| Subnet | Usable hosts | Broadcast |
|---|---|---|
| 192.168.10.0/26 | .1 to .62 | .63 |
| 192.168.10.64/26 | .65 to .126 | .127 |
| 192.168.10.128/26 | .129 to .190 | .191 |
| 192.168.10.192/26 | .193 to .254 | .255 |
For more practice, see how to calculate subnets for a Class C range.
10. A new department needs 450 hosts in one subnet. Which prefix length do you choose?
A /23 gives 512 addresses and 510 usable hosts, enough for 450 with room to grow. A /24 (254 hosts) is too small. For example, 10.20.4.0/23 runs from 10.20.4.1 to 10.20.5.254.
11. Which mask do you use on a point-to-point link between two routers?
A /30 gives exactly two usable addresses and is the traditional choice. A /31 wastes no addresses and is defined in RFC 3021 for point-to-point links; many current IOS and IOS XE platforms support it. Use /127 or /64 for IPv6 point-to-point links according to your addressing plan.
12. Users report "duplicate IP address" warnings. How do you find the other device?
Find the MAC address that owns the IP, then trace that MAC to a switch port:
R1# show arp | include 192.168.10.45
SW1# show mac address-table address 0050.56ab.12cd
SW1# show cdp neighbors
If the MAC is learned on an uplink, follow it to the next switch with CDP or LLDP until you reach an access port. Then fix the static assignment, or exclude static addresses from the DHCP pool with ip dhcp excluded-address.
13. A file transfer between two hosts is slow and the interface shows late collisions and CRC errors. What is the likely cause?
A duplex mismatch: one side runs full duplex and the other half duplex, usually because one end was hard-coded and the other left on auto. Check both ends with show interfaces GigabitEthernet0/1 and set them the same, preferably both to auto:
SW1(config)# interface GigabitEthernet0/1
SW1(config-if)# speed auto
SW1(config-if)# duplex auto
If CRC errors continue with matching settings, replace the cable or transceiver.
14. You must connect two buildings 2 km apart. Copper, multimode or single-mode fiber?
Single-mode fiber. Copper Ethernet is limited to 100 m per segment, and multimode fiber is meant for shorter runs inside or between nearby buildings. Single-mode with long-reach optics covers several kilometres. Match the transceivers on both ends to the fiber type.
15. Users on 2.4 GHz Wi-Fi complain about poor performance in a busy office. What do you change?
Put neighbouring access points on non-overlapping channels 1, 6 and 11, lower transmit power where cells overlap too much, and move capable clients to 5 GHz or 6 GHz, which have many more non-overlapping channels. Check for interference from non-Wi-Fi sources as well.
16. A Linux server can ping 8.8.8.8 but cannot resolve names. What do you check?
Routing works, so the problem is DNS. Check the resolver settings (resolvectl status or /etc/resolv.conf), test with nslookup example.com or dig, and confirm that an ACL or firewall is not blocking UDP and TCP port 53 to the DNS server.
17. A host has only an fe80:: IPv6 address and no global address. What is missing?
The host is not receiving router advertisements with a prefix. The router probably lacks IPv6 routing or an IPv6 address on the LAN interface:
R1(config)# ipv6 unicast-routing
R1(config)# interface GigabitEthernet0/0
R1(config-if)# ipv6 address 2001:db8:10::1/64
R1(config-if)# no shutdown
R1# show ipv6 interface brief
Without ipv6 unicast-routing, IOS does not send router advertisements, so hosts cannot use SLAAC.
18. Which transport would you choose for a VoIP call and for a file download, and why?
VoIP uses UDP (RTP runs over UDP) because late audio is useless and retransmission would only add delay. File downloads use TCP because every byte must arrive in order, and TCP retransmits lost segments and controls congestion.
19. An auditor finds enable password in your configs. What do you change?
Replace it with enable secret, which stores a hashed password, and encrypt any remaining clear-text passwords:
R1(config)# no enable password
R1(config)# enable secret <strong-password>
R1(config)# service password-encryption
R1(config)# security passwords min-length 10
service password-encryption uses weak, reversible Type 7 encoding, so it only stops casual shoulder surfing. Use secret for every user.
20. You inherit a network with no diagram. How do you find which devices connect where?
Use the Layer 2 discovery protocols. CDP is on by default on Cisco devices; LLDP is the standard for mixed vendors and may need enabling:
SW1# show cdp neighbors detail
SW1(config)# lldp run
SW1# show lldp neighbors
Combine the output with show ip route and show mac address-table to draw the map. Disable CDP and LLDP on ports facing untrusted networks, because they reveal device details.
Scenario-based CCNA questions for 2 to 5 years experience
21. Hosts in VLAN 20 on two switches cannot reach each other. Both access ports look fine. What next?
Check the trunk between the switches. VLAN 20 may be missing from the allowed list, not created on one switch, or pruned:
SW1# show interfaces trunk
SW1# show vlan brief
SW1(config)# interface GigabitEthernet1/0/24
SW1(config-if)# switchport trunk allowed vlan add 20
The VLAN must appear in "Vlans allowed and active in management domain" on both ends.
22. Configure a trunk to another switch that uses VLAN 99 as the native VLAN.
SW1(config)# interface GigabitEthernet1/0/24
SW1(config-if)# switchport trunk encapsulation dot1q
SW1(config-if)# switchport mode trunk
SW1(config-if)# switchport trunk native vlan 99
SW1(config-if)# switchport trunk allowed vlan 10,20,30,99
SW1(config-if)# switchport nonegotiate
The encapsulation dot1q line is only needed on platforms that also support ISL; on most current switches the command is not available because 802.1Q is the only option. switchport nonegotiate turns off DTP.
23. The switch logs a CDP native VLAN mismatch. What is the risk and the fix?
Untagged frames on one switch land in a different VLAN on the other, which leaks traffic between VLANs and can break spanning tree for those VLANs. Set the same native VLAN on both ends with switchport trunk native vlan 99, and use an unused VLAN, not VLAN 1, as the native VLAN.
24. A small branch has one router and one switch with three VLANs. How do you route between VLANs?
Use router-on-a-stick: one trunk to the router and a subinterface per VLAN.
R1(config)# interface GigabitEthernet0/0.10
R1(config-subif)# encapsulation dot1Q 10
R1(config-subif)# ip address 192.168.10.1 255.255.255.0
R1(config)# interface GigabitEthernet0/0.20
R1(config-subif)# encapsulation dot1Q 20
R1(config-subif)# ip address 192.168.20.1 255.255.255.0
R1(config)# interface GigabitEthernet0/0
R1(config-if)# no shutdown
The switch port toward the router must be a trunk. For more on how VLANs map to subnets, see VLANs and subnets.
25. You configured SVIs on a Layer 3 switch, but VLANs still cannot reach each other. Why?
Most often IP routing is off, or the SVI is down. Enable routing and check each SVI:
DSW1(config)# ip routing
DSW1# show ip interface brief | include Vlan
DSW1# show ip route connected
An SVI stays down if the VLAN does not exist in the VLAN database, the SVI is shut, or no port in that VLAN is up. Also check that hosts use the SVI address as their gateway.
26. An IP phone and a PC share one wall port. How do you configure the switch port?
SW1(config)# interface GigabitEthernet1/0/10
SW1(config-if)# switchport mode access
SW1(config-if)# switchport access vlan 10
SW1(config-if)# switchport voice vlan 20
SW1(config-if)# spanning-tree portfast
The phone learns the voice VLAN through CDP or LLDP-MED and tags its own traffic; the PC behind it sends untagged frames into VLAN 10.
27. A port on the access switch keeps going err-disabled after someone plugged in a small switch. What happened?
Either BPDU Guard or port security shut the port. Find out which:
SW1# show interfaces status err-disabled
SW1# show port-security interface GigabitEthernet1/0/7
SW1# show logging | include ERR
Remove the unauthorised switch, then bring the port back with shutdown and no shutdown. If you want automatic recovery, configure errdisable recovery cause bpduguard with an interval, but only after the cause is gone.
28. Limit an access port to the first two devices that connect and log any others without shutting the port.
SW1(config)# interface GigabitEthernet1/0/7
SW1(config-if)# switchport mode access
SW1(config-if)# switchport port-security
SW1(config-if)# switchport port-security maximum 2
SW1(config-if)# switchport port-security mac-address sticky
SW1(config-if)# switchport port-security violation restrict
restrict drops frames from unknown MACs, increments the violation counter and logs; protect drops silently; shutdown (the default) err-disables the port. Port security only works on access or static trunk ports, not dynamic ones.
29. An old access switch became the spanning-tree root after a reload, and traffic now takes a strange path. How do you fix it?
Set the root bridge on purpose. Make the core or distribution switch primary and its partner secondary for each VLAN:
DSW1(config)# spanning-tree vlan 10,20,30 root primary
DSW2(config)# spanning-tree vlan 10,20,30 root secondary
DSW1# show spanning-tree vlan 10
Or set the priority directly in steps of 4096, for example spanning-tree vlan 10 priority 4096. The lowest bridge ID (priority plus MAC) wins.
30. The network slows to a crawl, switch CPUs are high, and logs show MAC addresses flapping between ports. What is happening?
A Layer 2 loop, usually because spanning tree was disabled, a port was set to PortFast toward another switch, or an unmanaged device bridged two ports. Find the ports in the flapping messages, shut one link in the loop to stop the storm, then fix the cause. Prevent it with Rapid PVST+, BPDU Guard on all edge ports, and storm-control broadcast level on access ports.
31. An LACP EtherChannel between two switches will not come up. What do you check?
SW1# show etherchannel summary
SW1# show interfaces GigabitEthernet1/0/1 switchport
SW1# show lacp neighbor
All member ports must match on speed, duplex, switchport mode, access VLAN or trunk allowed and native VLANs. One side must be active; passive on both sides never forms a bundle. Ports shown with flag "s" are suspended because of a mismatch.
32. Configure a two-port Layer 2 LACP EtherChannel trunk.
SW1(config)# interface range GigabitEthernet1/0/1 - 2
SW1(config-if-range)# channel-group 1 mode active
SW1(config-if-range)# exit
SW1(config)# interface Port-channel1
SW1(config-if)# switchport mode trunk
SW1(config-if)# switchport trunk allowed vlan 10,20,30,99
Avoid mode on: it forms the channel without negotiation, and if the other side is not configured the same way it can cause a loop.
33. PCs take about 30 seconds to get a DHCP address after boot. What is a likely cause?
The access port is going through the spanning-tree listening and learning states before forwarding, and the DHCP client gives up or retries late. Enable PortFast on edge ports, ideally with BPDU Guard, and run Rapid PVST+:
SW1(config)# spanning-tree mode rapid-pvst
SW1(config)# spanning-tree portfast default
SW1(config)# spanning-tree portfast bpduguard default
The global portfast default applies only to access ports, not trunks.
34. A customer's switch connected to your distribution layer tries to become root. How do you protect the topology?
Apply Root Guard on the distribution ports facing that switch with spanning-tree guard root. If a superior BPDU arrives, the port goes into a root-inconsistent state and stops forwarding until the superior BPDUs stop. Use BPDU Guard instead on ports where no switch should ever appear.
35. What would you do to harden unused switch ports?
SW1(config)# interface range GigabitEthernet1/0/30 - 48
SW1(config-if-range)# switchport mode access
SW1(config-if-range)# switchport access vlan 999
SW1(config-if-range)# switchport nonegotiate
SW1(config-if-range)# shutdown
VLAN 999 is an unused "parking" VLAN with no SVI. Static access mode and disabled DTP stop someone from negotiating a trunk.
36. A wireless access point in local mode is connected to an access port. Is that right?
Yes for a lightweight AP in local mode: it tunnels client traffic to the WLC through CAPWAP, so an access port in the AP management VLAN is enough. An AP in FlexConnect mode that switches client traffic locally for several WLANs needs a trunk carrying those VLANs. A WLC connects to the switch with a trunk, often bundled as a LAG.
37. A router cannot reach 172.16.50.0/24. Walk through your checks.
show ip route 172.16.50.0to see whether any route matches, including the default route.- If a route exists, ping and trace to the next hop, and check that the next-hop router has a return route.
- If no route exists, check the routing protocol (
show ip ospf neighbor,show ip protocols) or the static route. - Check for ACLs on the path with
show ip access-listsand the interface configuration.
Asymmetric return paths and missing return routes are as common as missing forward routes. Our guide to ping, traceroute and netstat covers the host side.
38. A router learns 10.1.0.0/16 through OSPF and has a static route to 10.1.1.0/24. Which route does traffic to 10.1.1.5 use?
The static /24, because the router first picks the longest prefix match. Administrative distance is compared only between routes to the same prefix length; then the metric breaks ties within one protocol.
| Route source | Default administrative distance |
|---|---|
| Connected | 0 |
| Static | 1 |
| eBGP | 20 |
| EIGRP (internal) | 90 |
| OSPF | 110 |
| RIP | 120 |
| iBGP | 200 |
39. The branch has a primary link running OSPF and a backup internet VPN. How do you make the backup take over only when OSPF loses the route?
Use a floating static route with an administrative distance higher than OSPF's 110:
R1(config)# ip route 10.0.0.0 255.0.0.0 172.31.255.2 200
The static route stays out of the routing table while the OSPF route exists, and is installed when the OSPF route disappears. Verify with show ip route 10.0.0.0 during a failover test.
40. Two OSPF routers are stuck in EXSTART or EXCHANGE. What is the classic cause?
An MTU mismatch on the link. The routers see each other's hellos, but database description packets are rejected. Compare MTU with show interfaces or show ip ospf interface and set them equal. ip ospf mtu-ignore hides the symptom and should only be a temporary workaround.
41. OSPF neighbors do not appear at all. List the checks.
R1# show ip ospf interface GigabitEthernet0/0
R1# show ip ospf neighbor
R1# show ip protocols
- Interfaces in the same subnet and the same area.
- Matching hello and dead timers.
- Matching authentication type and key, if used.
- The interface is not passive.
- Unique router IDs.
- Matching network type, and no ACL blocking OSPF (IP protocol 89) or multicast 224.0.0.5 and 224.0.0.6.
42. Configure single-area OSPF on a branch router and stop hellos on the LAN.
R1(config)# router ospf 1
R1(config-router)# router-id 1.1.1.1
R1(config-router)# passive-interface default
R1(config-router)# no passive-interface GigabitEthernet0/1
R1(config-router)# exit
R1(config)# interface GigabitEthernet0/0
R1(config-if)# ip ospf 1 area 0
R1(config)# interface GigabitEthernet0/1
R1(config-if)# ip ospf 1 area 0
The LAN subnet on Gi0/0 is still advertised, but no hellos are sent there. The older network 192.168.1.0 0.0.0.255 area 0 form under the process works too.
43. Two routers are connected by a single Ethernet link, and OSPF still elects a DR and BDR. Is there a better option?
Set the OSPF network type to point-to-point on both ends with ip ospf network point-to-point. There is no DR/BDR election, adjacency forms faster, and the link appears as a simpler LSA.
44. You want R1 to be the DR on a shared segment, but R3 is DR. You set priority 255 on R1 and nothing changed. Why?
DR election is not preemptive. R3 stays DR until the adjacency resets. After setting ip ospf priority 255 on R1's interface, reset OSPF in a maintenance window with clear ip ospf process, or set priority 0 on routers that should never become DR or BDR.
45. The OSPF router ID changed after someone added a loopback, and now logs show duplicate router IDs. How do you prevent this?
The router ID is chosen once, at process start: the manual router-id first, then the highest loopback IP, then the highest active interface IP. Set it manually on every router with router-id, keep a register of IDs, and run clear ip ospf process to apply a change.
46. How do you send all internet traffic to the ISP and share that default route with internal OSPF routers?
R1(config)# ip route 0.0.0.0 0.0.0.0 203.0.113.1
R1(config)# router ospf 1
R1(config-router)# default-information originate
Internal routers then show an O*E2 default route. Add always only if you want it advertised even when the static default is missing.
47. A monitoring server needs to reach one device across a different path than the rest of the subnet. What do you configure?
A host route, which wins because it is the longest possible prefix:
R1(config)# ip route 10.50.0.10 255.255.255.255 10.1.1.2
R1(config)# ipv6 route 2001:db8:50::10/128 2001:db8:1::2
48. Configure an IPv6 default route on a branch router.
R1(config)# ipv6 unicast-routing
R1(config)# ipv6 route ::/0 2001:db8:ffff::1
R1# show ipv6 route ::/0
If the next hop is a link-local address, you must name the exit interface as well, for example ipv6 route ::/0 GigabitEthernet0/1 fe80::1.
49. A traceroute shows packets bouncing between R1 and R2 until the TTL expires. What is wrong?
A routing loop. Each router's best route for that destination points to the other, often because of two static routes pointing at each other or a summary route without a matching specific route. Check show ip route for the destination on both routers and remove or correct the bad route. Adding a Null0 route for summarised ranges stops loops for unused addresses inside the summary.
50. Internal users cannot browse after you configured PAT. What do you verify?
R1(config)# access-list 1 permit 192.168.0.0 0.0.255.255
R1(config)# ip nat inside source list 1 interface GigabitEthernet0/1 overload
R1(config)# interface GigabitEthernet0/0
R1(config-if)# ip nat inside
R1(config)# interface GigabitEthernet0/1
R1(config-if)# ip nat outside
R1# show ip nat translations
R1# show ip nat statistics
The usual mistakes are swapped inside and outside interfaces, an ACL that does not match the user subnet, and a missing default route to the ISP. If the statistics show hits but no replies, check the return path. Our post on NAT and subnetting explains the address design behind it.
51. An internal web server at 192.168.1.10 must be reachable from the internet as 203.0.113.10. How?
Use static NAT, or static PAT for a single port:
R1(config)# ip nat inside source static 192.168.1.10 203.0.113.10
! or only HTTPS:
R1(config)# ip nat inside source static tcp 192.168.1.10 443 203.0.113.10 443
Pair it with an inbound ACL or firewall policy that allows only the ports the server needs.
52. The ISP gave you 203.0.113.20 to .30 for outbound NAT. How do you use the pool?
R1(config)# ip nat pool PUBLIC 203.0.113.20 203.0.113.30 netmask 255.255.255.0
R1(config)# ip nat inside source list 1 pool PUBLIC overload
Without overload it is dynamic NAT, and the 12th simultaneous user gets no translation. With overload, many users share each address by port number.
53. Clients in VLAN 30 get no address, but the DHCP server on 10.0.0.5 serves other VLANs. What is missing?
The DHCP relay on the VLAN 30 gateway. DHCP discovers are broadcasts and do not cross routers on their own:
DSW1(config)# interface vlan 30
DSW1(config-if)# ip helper-address 10.0.0.5
Also check that the server has a scope for the VLAN 30 subnet, because it picks the scope from the relay's address.
54. Configure a branch router as the DHCP server for 192.168.50.0/24, keeping .1 to .20 for static devices.
R1(config)# ip dhcp excluded-address 192.168.50.1 192.168.50.20
R1(config)# ip dhcp pool BRANCH-LAN
R1(dhcp-config)# network 192.168.50.0 255.255.255.0
R1(dhcp-config)# default-router 192.168.50.1
R1(dhcp-config)# dns-server 192.168.50.5 1.1.1.1
R1(dhcp-config)# lease 1
Verify with show ip dhcp binding and show ip dhcp pool.
55. Log timestamps from different devices do not line up during an incident. What do you configure?
R1(config)# clock timezone IST 5 30
R1(config)# ntp server 10.0.0.1
R1(config)# service timestamps log datetime msec localtime show-timezone
R1# show ntp associations
R1# show ntp status
Correct time is also needed for certificates and for matching logs to a syslog server or SIEM.
56. Send only warnings and more severe messages to a central syslog server.
R1(config)# logging host 10.0.0.50
R1(config)# logging trap warnings
Syslog severities run from 0 (emergencies) to 7 (debugging): emergencies, alerts, critical, errors, warnings, notifications, informational, debugging. logging trap warnings sends levels 0 to 4.
57. Your monitoring tool uses SNMPv2c with community "public". What do you recommend?
Move to SNMPv3 with authentication and encryption, and restrict which hosts can query:
R1(config)# access-list 20 permit 10.0.0.60
R1(config)# snmp-server group NMS v3 priv access 20
R1(config)# snmp-server user nmsuser NMS v3 auth sha <auth-pass> priv aes 128 <priv-pass>
R1(config)# no snmp-server community public
58. Voice calls across the WAN are choppy at busy times. What QoS approach do you describe?
Classify and mark voice close to the source (DSCP EF, decimal 46), trust markings only at the trust boundary such as the IP phone, and give voice a priority queue (LLQ) with a bandwidth limit on the congested WAN interface. Use shaping on the WAN edge to match the provider's committed rate, because shaping buffers excess traffic while policing drops or re-marks it.
59. The ISP hands out the WAN address by DHCP. How do you configure the router interface?
R1(config)# interface GigabitEthernet0/1
R1(config-if)# ip address dhcp
R1(config-if)# no shutdown
R1# show dhcp lease
The router also installs a default route from the DHCP offer unless told otherwise.
60. HR users must not reach the payroll database on TCP 1433, but everything else should work. Write and place the ACL.
R1(config)# ip access-list extended HR-NO-PAYROLL
R1(config-ext-nacl)# deny tcp 192.168.20.0 0.0.0.255 host 10.10.10.50 eq 1433
R1(config-ext-nacl)# permit ip any any
R1(config)# interface GigabitEthernet0/0.20
R1(config-subif)# ip access-group HR-NO-PAYROLL in
Place extended ACLs close to the source and standard ACLs close to the destination. Check hit counters with show ip access-lists HR-NO-PAYROLL.
61. You applied a new ACL and now all traffic on the interface stops. Why?
Every ACL ends with an implicit deny any. If your entries only deny, nothing is permitted. Add the needed permit statements, and when editing a live ACL, add lines by sequence number instead of removing and re-applying it, so the interface is never left without a filter or with a wrong one.
62. Allow SSH to the routers only from the management subnet 10.99.0.0/24.
R1(config)# access-list 10 permit 10.99.0.0 0.0.0.255
R1(config)# line vty 0 15
R1(config-line)# access-class 10 in
R1(config-line)# transport input ssh
access-class filters connections to the device itself; ip access-group filters traffic passing through an interface.
63. Users in VLAN 10 are getting addresses from a rogue DHCP server someone plugged in. How do you stop it?
Enable DHCP snooping, trust only the uplink toward the real server, and rate-limit untrusted ports:
SW1(config)# ip dhcp snooping
SW1(config)# ip dhcp snooping vlan 10
SW1(config)# interface GigabitEthernet1/0/48
SW1(config-if)# ip dhcp snooping trust
SW1(config)# interface range GigabitEthernet1/0/1 - 24
SW1(config-if-range)# ip dhcp snooping limit rate 15
SW1# show ip dhcp snooping binding
If clients stop getting addresses through a relay after enabling it, the inserted option 82 may be the cause; no ip dhcp snooping information option is the common fix.
64. How do you defend against ARP spoofing on an access VLAN?
Enable Dynamic ARP Inspection, which checks ARP packets against the DHCP snooping binding table:
SW1(config)# ip arp inspection vlan 10
SW1(config)# interface GigabitEthernet1/0/48
SW1(config-if)# ip arp inspection trust
SW1# show ip arp inspection statistics vlan 10
Hosts with static IPs need ARP ACLs, or DAI will drop their ARP replies.
65. Logs show repeated failed SSH logins on an edge router. What do you do?
Treat it as an attack on the management plane. Restrict VTY access to the management subnet (question 62), slow down guessing, and alert on it:
R1(config)# login block-for 120 attempts 5 within 60
R1(config)# login on-failure log
R1(config)# security passwords min-length 12
Then move logins to AAA with TACACS+ or RADIUS and MFA, and check whether the router's management interface should be reachable from the internet at all.
66. Set up central authentication with TACACS+ and fall back to local accounts if the server is down.
R1(config)# aaa new-model
R1(config)# tacacs server TAC1
R1(config-server-tacacs)# address ipv4 10.0.0.20
R1(config-server-tacacs)# key <shared-secret>
R1(config)# aaa authentication login default group tacacs+ local
R1(config)# aaa authorization exec default group tacacs+ local
R1(config)# aaa accounting commands 15 default start-stop group tacacs+
TACACS+ encrypts the whole payload and separates authentication, authorization and accounting, so it suits device administration. RADIUS is more common for network access, such as 802.1X and VPN users. Keep one local account and test it before you log out.
67. A company wants branch offices to connect to HQ, and staff to connect from home. Which VPN types fit?
Site-to-site IPsec VPNs between branch routers or firewalls and HQ, so whole subnets talk without client software. Remote-access VPNs (IPsec or TLS-based clients) for staff at home, authenticated per user, ideally with MFA.
68. The guest Wi-Fi uses WPA2-Personal with a password printed on the wall. What would you suggest?
Isolate guests in their own VLAN with internet-only access, rotate the passphrase regularly, and use WPA3 where clients support it, because WPA3-Personal uses SAE and resists offline password guessing better than WPA2-PSK. For staff, use WPA2 or WPA3-Enterprise with 802.1X and RADIUS, so each user has their own credentials.
Senior and design scenario questions
69. Design the network for a campus with three buildings and about 1,500 users.
Use a hierarchical design. Access switches in each building connect to a distribution pair, and the distribution pairs connect to a core. With only three buildings, a collapsed core (two tiers, core and distribution combined) is often enough. Run Layer 3 links between distribution and core so spanning tree stays inside each building, use LACP bundles for uplinks, and plan addressing per building so you can summarise. In a data center, a spine-leaf design gives predictable east-west latency because every leaf is one hop from every spine.
70. Hosts lose their gateway when the distribution switch that owns it fails. How do you add redundancy?
Use a first hop redundancy protocol: HSRP (Cisco), VRRP (standard) or GLBP (Cisco, with load sharing). Hosts point to a virtual IP that moves to the standby switch on failure:
DSW1(config)# interface vlan 10
DSW1(config-if)# ip address 192.168.10.2 255.255.255.0
DSW1(config-if)# standby 10 ip 192.168.10.1
DSW1(config-if)# standby 10 priority 110
DSW1(config-if)# standby 10 preempt
The 200-301 v1.1 blueprint asks you to describe FHRPs; configuring HSRP is a common job interview task rather than an exam objective. Align the HSRP active switch with the spanning-tree root for that VLAN.
71. Two customers in your data center use the same 10.0.0.0/24 range on one router. How do you keep them apart?
Put each customer in its own VRF, so each has a separate routing table:
R1(config)# vrf definition CUST-A
R1(config-vrf)# rd 65000:1
R1(config-vrf)# address-family ipv4
R1(config)# interface GigabitEthernet0/2
R1(config-if)# vrf forwarding CUST-A
R1(config-if)# ip address 10.0.0.1 255.255.255.0
R1# show ip route vrf CUST-A
Applying vrf forwarding removes any existing IP address from the interface, so re-enter it afterwards.
72. You must add VLAN 40 to 200 access switches by Friday. How would you do it?
Automate it instead of logging in to each switch. Store the change as code, test it on a lab switch, run it in batches and verify with show commands. An Ansible task using the cisco.ios collection looks like this:
- name: Add VLAN 40 to access switches
hosts: access_switches
gather_facts: false
tasks:
- name: Create VLAN 40
cisco.ios.ios_config:
parents:
- vlan 40
lines:
- name USERS-FLOOR4
- name: Save configuration
cisco.ios.ios_config:
save_when: modified
The blueprint expects you to recognise what Ansible and Terraform do; interviewers for network automation roles will ask you to explain idempotency, inventories and how you roll back.
73. A REST API call to the network controller returns 401, and another returns 404. What do they mean?
401 Unauthorized means the request lacked valid authentication (missing or expired token, wrong basic credentials). 404 Not Found means the URI or resource does not exist. REST APIs map CRUD to HTTP verbs: POST creates, GET reads, PUT or PATCH updates, DELETE removes. Data is usually encoded as JSON:
{
"interface": "GigabitEthernet1/0/10",
"enabled": true,
"vlan": 10,
"description": "Floor 2 printer"
}
Be ready to say that this is an object with four key-value pairs: a string, a boolean, a number and a string.
74. Your manager asks how a controller-based network differs from the current one. How do you explain it?
In a traditional network every device runs its own control plane and is configured one by one. In a controller-based (software-defined) network, a controller holds the policy and pushes it to devices through southbound APIs such as NETCONF or REST, while applications and scripts talk to the controller through northbound APIs. Fabrics separate the underlay (the physical routed network) from the overlay (tunnels such as VXLAN that carry user traffic and policy).
75. Where can AI and machine learning help in network operations, and what are the risks?
Predictive AI and machine learning spot anomalies in telemetry, forecast link saturation and correlate alarms to a likely root cause. Generative AI can summarise incidents, explain configurations and draft changes or scripts. The risks are wrong suggestions stated confidently and sensitive data in prompts, so keep a human review step and test generated configuration in a lab first. The current v1.1 blueprint lists this as objective 6.4.
Multi-step troubleshooting tickets
76. Ticket: "After last night's change, everyone in VLAN 30 lost connectivity." What do you suspect?
A classic cause is a trunk change typed as switchport trunk allowed vlan 40 instead of switchport trunk allowed vlan add 40, which replaces the whole allowed list. Check show interfaces trunk on the uplinks, compare with the archived config, and restore the list with add. Prevent it with peer review, configuration archives (archive and show archive config differences) and a pre-change backup.
77. Ticket: "The new branch gets IP addresses but cannot open any website."
- From a client, ping the gateway, then a public IP, then a name. This separates LAN, routing or NAT, and DNS.
- If public IPs fail, check the router's default route (
show ip route 0.0.0.0) and NAT (show ip nat translations, inside and outside interfaces). - If IPs work but names fail, check the DNS servers in the DHCP pool and whether an ACL blocks port 53.
- If small pages load but large ones hang, suspect an MTU problem over a VPN or PPPoE link and adjust
ip tcp adjust-mss.
78. Ticket: "The internet is slow every morning around 9:30."
Look at the uplink load and errors during that window: show interfaces GigabitEthernet0/1 | include rate|errors|drops, plus history from your monitoring system. If utilisation is near line rate, find the top talkers with NetFlow or the firewall, and decide between QoS, scheduling backups or updates outside work hours, and more bandwidth. If errors or output drops rise without high utilisation, look at duplex, cabling and queue settings instead.
79. Ticket: "OSPF routes to the data center keep disappearing and coming back."
Check whether the adjacency is flapping: show logging | include OSPF for ADJCHG messages and show ip ospf neighbor for a low uptime. Then look at the physical link for errors, CRCs and interface resets, because a flapping link is the most common cause. Also check CPU load at the times of the drops and whether hello and dead timers were changed on only one side.
80. Ticket: "A switch stack was replaced and now users on floor 3 get addresses from the wrong subnet."
The access ports were probably left in the default VLAN, or the uplink trunk carries a different native VLAN than before, so DHCP requests reach the wrong scope. Compare show vlan brief and show interfaces trunk with the old configuration, put the ports back in the right access VLANs, and fix the native VLAN on both ends. Afterwards, release and renew the clients' leases and confirm with show ip dhcp binding or the DHCP server's logs.
How to prepare for a scenario-based CCNA interview
- Build the scenarios in Cisco Packet Tracer or a virtual lab (Cisco Modeling Labs, EVE-NG or GNS3) and break them on purpose: wrong VLAN, MTU mismatch, swapped NAT interfaces, missing helper address.
- Learn the verification commands well enough to read their output aloud: what a "BLK" port, an "s" flag in EtherChannel or an O*E2 route means.
- Practise answering out loud in under two minutes: cause, proof, fix, prevention.
- Know the basics of Linux networking too; DevOps and cloud roles expect you to troubleshoot from the server side. Our scenario-based Linux interview questions cover that half, and the 200+ DevOps interview questions hub links to every topic.
- If you plan to sit the exam, check Cisco's timeline: v1.1 testing ends on 2 February 2027 and v2.0 starts on 3 February 2027.
DevOps Training Institute runs classroom batches in Kharadi, Pune and live online classes across India. The Linux administration course covers server networking, firewalls and troubleshooting that pair with the CCNA topics above, and the DevOps course builds on them with automation and cloud networking.
FAQs
What are scenario-based CCNA interview questions?
They describe a fault or a design request, such as hosts that cannot reach each other across a trunk, and ask how you would find the cause and fix it. Interviewers want to hear an ordered approach and the right show commands, not only the final answer.
Is the CCNA exam code still 200-301?
Yes. The current exam is CCNA v1.1 (200-301), a 120-minute exam. Cisco states that the last day to test on v1.1 is 2 February 2027 and that CCNA v2.0 goes live for testing on 3 February 2027.
Which CCNA topics carry the most weight?
In the 200-301 v1.1 blueprint, IP Connectivity is 25%, Network Fundamentals and Network Access are 20% each, Security Fundamentals is 15%, and IP Services and Automation and Programmability are 10% each.
Are EIGRP and BGP on the CCNA exam?
No. The 200-301 v1.1 blueprint covers static routing and single-area OSPFv2. EIGRP, BGP and HSRP configuration still come up in job interviews, so learn the basics, but focus exam practice on OSPF and static routes.
How should I answer a CCNA troubleshooting scenario?
Work from the physical layer up. State the most likely cause, name the command that proves it, give the fix, and say how you would confirm it and prevent a repeat. Mentioning what you would check in the logs and in change records also helps.
Which IOS commands should I know for CCNA interviews?
At minimum: show ip interface brief, show running-config, show interfaces, show vlan brief, show interfaces trunk, show spanning-tree, show etherchannel summary, show ip route, show ip ospf neighbor, show ip nat translations, show ip dhcp binding and show access-lists.
Is Packet Tracer enough to practise these scenarios?
Packet Tracer covers most CCNA scenarios, including VLANs, trunks, STP, OSPF, NAT, DHCP and ACLs. For features it does not fully support, or for automation practice with real IOS XE images, use Cisco Modeling Labs or another virtual lab.
How is this page different from the 150+ CCNA questions post?
The 150+ post covers definitions and networking basics for freshers. This page is only scenarios: each question gives a symptom or design request and expects a troubleshooting order, IOS commands and a fix.
What's Your Reaction?
Like
0
Dislike
0
Love
0
Funny
0
Angry
0
Sad
0
Wow
0
